1 / 5
Vertical machining center machine

Price:
price negotiable
Brand Name:
Akira-SeikiCountry Region:
U.S.AModel No:
V4XP


Akira-Seiki

Country: U.S.A
Main Products: Machining center, lathe
View more
Price:
price negotiable
Brand Name:
Akira-SeikiCountry Region:
U.S.AModel No:
V4XP


Akira-Seiki

U.S.A
Main Products:
Machining center, lathe

商品详情
V3 | V4 | V5 | |||||
V3 XP | V4 XP | V5 XP | |||||
控制系统 | AKIRA M:845 (Fanuc G代码兼容) | ||||||
行程 | |||||||
x轴行程 | 毫米/英寸 | 815 / 32.1 | 1050 / 41.3 | 1300 / 51.2 | |||
y轴行程 | 毫米/英寸 | 540/21.3 | 540 / 19.8 | 540 / 21.3 | |||
z轴行程 | 毫米/英寸 | 560/22 | 560 / 22 | 560 / 22 | |||
主轴前端至台面 | 毫米/英寸 | 75~635/3~25 | 75~635/3~25 | 75~595 / 3~25 | |||
主轴中心到转向柱盖 | 毫米/英寸 | 550 /21.7 | 550 / 21.7 | 550 / 21.7 | |||
桌子 | |||||||
桌子大小(长x宽) | 毫米/英寸 | 950 x 480 / | 1200 x 480 / | 1450 x 480 / | |||
37.4 x 19 | 47.2 x 19 | 57 x 19 | |||||
t 形槽 | 毫米/英寸 | 18 x 80 x 5个插槽/ | 18 x 80 x 5个插槽/ | 18 x 80 x 5个插槽/ | |||
0.7 x 3.15 x 5个插槽 | 0.7 x 3.15 x 5个插槽 | 0.7 x 3.15 x 5个插槽 | |||||
最大值装货 | 千克/磅 | 1080 / 2380 | 1176 / 2592 | 1296 / 2857 | |||
标准装载 | 千克/磅 | 900 / 1984 | 980 / 2160 | 1080 / 2381 | |||
轴 | |||||||
最大值功率(峰值) | 大功率(High Power)ˌ高压(High Pressure)ˌ高性能(High Performance)ˌ高聚物(High Polymer) | V = 30 | XP = 35 | V = 30 | XP = 35 | V= 30 | XP = 35 |
最大值速度 | 每分钟转数 | 10,000 | 12,000 | 10,000 | 12,000 | 10,000 | 12,000 |
8000转/分(可选) | 8000转/分(可选) | 8000转/分(可选) | |||||
主轴锥度 | BT40 | BT40 | BT40 | ||||
饲料 | |||||||
X / Y / Z快速进给 | 米/分钟 | 40 / 40 / 25 | 40 / 40 / 25 | 40 / 40 / 25 | |||
英寸/分钟(inches per minute的缩写) | 1574 / 1574 / 984 | 1574/1574 /984 | 1574 / 1574 / 984 | ||||
44/44/25 | 44/44/25 | 44 / 44 / 25 | |||||
1732 /1732 /984 | 1732/ 1732 /984 | 1732 / 1732 / 984 | |||||
切削进给X / Y / Z | 米/分钟 | 2010/10/10 | 2010/10/10 | 2010/10/10 | |||
英寸/分钟(inches per minute的缩写) | 394 / 394 / 394 | 394/394/394 | 394 / 394 / 394 | ||||
2012/12/10 | 2012/12/10 | 2012/12/10 | |||||
472 / 472 / 394 | 472 / 472 / 394 | 472 / 472 / 394 | |||||
准确(性) | |||||||
配置 | 毫米/英寸 | 0.01 / 0.00039 | 0.01 / 0.00039 | 0.01 / 0.00039 | |||
可重复性 | 毫米/英寸 | 0.003 / 0.00012 | 0.003 / 0.00012 | 0.003 / 0.00012 | |||
ATC(臂式) | |||||||
最大值工具储存 | - | 28吨 | 28吨 | 28吨 | |||
最大值工具直径 | 毫米/英寸 | 65 / 2.6 | 65 / 2.6 | 65 / 2.6 | |||
最大值工具直径 | 毫米/英寸 | 130 / 5.1 | 130 / 5.1 | 130 / 5.1 | |||
(没有邻居工具) | |||||||
最大值工具长度 | 毫米/英寸 | 250 / 9.8 | 250 / 9.8 | 250 / 9.8 | |||
最大值工具重量 | 千克/磅 | 7月15日 | 7月15日 | 7月15日 | |||
换刀时间(T到T,60hz) | 第二 | 2.2 | 2.2 | 2.2 | |||
其他 | |||||||
冷却液箱容量 | 升/加仑 | 350 / 92.5 | 350 / 92,5 | 400 / 105.7 | |||
碎片处理 | - | 抽屉 | 抽屉 | 抽屉 | |||
芯片螺钉 | 芯片螺钉 | 芯片螺钉 | |||||
气压要求 | 兆帕/磅/平方英寸 | 0.5 / 72.5 | 0.5 / 72.5 | 0.5 / 72.5 | |||
电源要求 | kVA | 30 | 30 | 30 | |||
尺寸(宽x深) | 毫米/英寸 | 2900 x 2240 / 114 x 88 | 3300 x 2240 / 130 x 88 | 3800 x 2240 / 146 x 88 | |||
3020 x 2240 / 119 x 88 | 3370 x 2240 / 133x 88 | 3870 x 2240 / 153 x 88 | |||||
重量 | 千克/磅 | 5700 / 12566 | 6600 / 14550 | 7400 / 16314 | |||
6000 / 13227 | 6900 / 15211 | 7700 / 16975 |
