Air pressure surface grinding (polishing) machine

Price:
price negotiable
Brand Name:
KAO-YUCountry Region:
Taiwan, ChinaModel No:
900


KAO-YU

Country: Taiwan, China
Main Products: Polishing and grinding machine
View more
Price:
price negotiable
Brand Name:
KAO-YUCountry Region:
Taiwan, ChinaModel No:
900


KAO-YU

Taiwan, China
Main Products:
Polishing and grinding machine

Product information
规格表 | 900 型 |
盘面外径 | 916 mm |
最大工作物直径 | 342 mm (368 mm) |
最小工作物厚度 | 0.3 mm |
加工轴数 | 四轴 |
最大加工压力 | 每轴 80kg |
表面精度 | 0.2-0.5 u |
盘面转速 | 10-60 R.P.M. |
主轴马力(HP) | 7.5 HP 无段变速 |
自动循环液系统 | 1/2HP(含搅拌器) |
自动控制器 | 可圈数控制或时数控制 |
电压 | 三相220V |
机械重量 | 約1600 Kg |
机械尺寸(长x宽x高) | 1500x1500x1900 mm |
标准附件 | 依实际配备为准 |
*规格、尺寸及配备如有变更,恕不另行通知 |
特点与应用
1. 本机适合于大量生产及高精密度操作。
2. 工作物的平面精度可达到0.2μ-0.5μ。
3. 本机适用不同形态,不同材质之物品同时加工。
4. 没有温度及变形的影响,即使此工作物薄到 0.20m/m。
5. 在加工当中,可作磨盘修整,不需停车。
选购配备
1. 盘面水冷却循环系统
2. 定时定量喷洒器
3. 不锈钢修整圈
4. 钻石修盘器
5. 精密平尺
6. 花岗岩检测平台
7. 电控系统(可程式控制器及5.7"彩色触控式萤幕)
