Material： Steel

Size: 130*80*47

Clamping Range: 0-120mm

Repeatability： ±0.01 mm

Install 4 ∅16 pull studs to compatible with TK Q52 Manual Quick-Change Chuck

Install centering plate and pull stud 50 to compatible with  ITS Chuck 100

52mm Pull Studs Spacing

Clamping Force: 25KN

Max Torque：90Nm

Weight：3.1kg

Tips：Install centering plate 100 or Plate G to compatible with  ITS Chuck 100.

We are T-KING CLAMP, committed to continuously reduce the clamping time of parts, greatly improve the machine operation rate. We are not only a fixture manufacturer, but also an intelligent equipment company focusing on the research and development and innovation of modular clamping systems, so that single pieces of small batches of workpiece clamping can be as easy, efficient and creative as Lego bricks. 80% of standardized modules +20% of customized solutions, under the premise of ensuring the consistency and interchangeability between different devices, to meet your specific application needs and more stringent process requirements, in the core technology of the clamping system "domestic replacement" on the road solid forward, helping enterprises to break through the upgrade dilemma of manual clamping to automatic make-up clamping. Make every minute of the machine more valuable!

Smart T-KING CLAMP offers a wide range of manual zero point quick change systems for three -, four - and five-axis machining centers and a wide range of self-centering vises. These types of vise are also ideal for pallet storage to automate workpiece processing. The modular clamping system is simple and easy to operate under the premise of meeting your high requirements for product performance, greatly improving the equipment operation rate and reducing the unit part processing cost.
