Product information
The mechanical compound drilling rig is that the rotary table is driven by the AC frequency conversion motor, and the winch and the mud pump are driven by the diesel engine through the chain box. Greatly simplifies the rotary mechanical drive system and improves Operability. It is mechanical drilling rig with part of the function of electric drilling rigs, improve the performance-price ratio of drilling rigs. The Winch is a closed chain drive winch. The gear shift with pneumatic clutch has four positive and two reverse gears. The handbrake adopts hydraulic disc brake and the auxiliary brake adopts electromagnetic eddy current brake. All kinds of instruments are concentrated in the driller's room. The driller's operation is simple and direct. Adopt integral chain box and car, good sealing performance, high modularization and convenient installation. The winch is equipped with emergency motor, when the power can not be transferred to the winch due to failure, it can be used for lifting drilling tools, reducing downhole accidents and realizing safe drilling. The turntable is independently driven by AC frequency conversion motor. The speed of the turntable is stepless between 0-240R/MIN.
