Name: 3D Fully Automatic In-Line Solder Paste Printing and Inspection Machine
Brand: Meet Your Hope
Price: price negotiable
Availability: InStock

1 / 3

3D Fully Automatic In-Line Solder Paste Printing and Inspection Machine

Price：

price negotiable

Brand Name：

Meet Your Hope

Country Region：

China

Model No：

Mirage series

Post Requirements

Meet Your Hope icon

Country： China

Main Products： 2D AOI inspection equipment, 3D AOI inspection equipment, 3D SPI solder paste inspection equipment, JUKI shaped insertion machine, SMT complete line solution

Price：

price negotiable

Brand Name：

Meet Your Hope

Country Region：

China

Model No：

Mirage series

Post Requirements

Meet Your Hope icon

China

Main Products：

2D AOI inspection equipment, 3D AOI inspection equipment, 3D SPI solder paste inspection equipment, JUKI shaped insertion machine, SMT complete line solution

Product information

Product Parameter

Model	Mirage	Mirage-D	Mirage-L	Mirage-XL	Mirage-1500
Lighting Systems	RGB+White LED Ring Light Source
Lighting Systems	3D bidirectional digital projection
Imaging System	5M/12M Industrial High Speed Camera
Resolution	5M：10μm-15μm（tunable) 12M: 8μm-10μm(tunable），15μm（selectable)
FOV Dimension	37.430mm (5M,15μm) 40.930.7mm (12M,10μm)
Height Measurement	Measurement of parts up to 8 mm in height
Height Measurement Accuracy	1μm
Machine Weight	950kg	1090kg	1090kg	1150kg	1290kg
Machine size(mm)	W1080×D1300×H1850	W1160×D1470xH1875	W1160×D1470xH1875	W1300×D1470xH1875	W1300×D1440xH1815
Machine size(mm)			W1645xD1470xH1875 （Add 230 extension rails on both sides)	W1720xD1470xH1875 （Add 210 extension rails on both sides)	W2310xD1440xH1815 （Add 505 extension rails on both sides)
Substrate size(mm)	5070~510460	monorails：5070~510590	single segment：5070~540610	single segment：5070~680610	single segment：5070~800610
		dual-track (system)：5070~510330	segmentation：5070~850610	segmentation：5070~990610	segmentation：5070~1100610
			Extension rails on both sides：5070-1000610	Extension rails on both sides：5070-1200610	Extension rails on both sides：5070-1500610
Substrate Thickness	0.6~6mm	0.6~6mm	0.6~6mm	0.6~6mm	0.6~10mm
Inspection Principle	2D imaging data analysis + 3D imaging data analysis
Inspection speed	350ms/FOV(2D+3D)
Defect detection	Less tin, more tin, continuous tin, offset, leakage, short circuit, pull tip, bad shape, etc.
Substrate transport system	ubstrate fixing: Bottom-up fixing, automatic plate entry/exit and automatic width adjustment system, complying with SMEMA standard.
Substrate transport system	Track height: 900±20mm
Power supply specifications	AC 220V 50/60Hz 1.9KVA
Air Pressure Specifications	0.5MPa
Environmental Requirements	Temperature: 5-40°C, relative humidity: 25%-80% frost-free
Link Port	Standard SMEMA interface

Product Presentation

3D Fully Automatic In-Line Solder Paste Printing Inspection Machine
Along with the increasing precision of electronic products, SMD components are becoming more and more miniature, the quality of solder paste printing is becoming more and more important. JUTZE SPI can effectively ensure good quality of solder paste printing, improve the printing quality, significantly reduce the possible existence of finished product defects, and effectively save the manpower and time cost of human error correction to improve the production efficiency and capacity.
Mirage adopts the most advanced dual projection technology, walk-stop dynamic image taking, all-round shadow-free testing, intelligent optimisation of the detection path, with high precision, fast detection, stable testing, easy operation and so on.
1、Double light source digital shadow-finding detection without shadow, high precision.
2、Intelligent optimisation of the testing route with high testing efficiency.
3, 3D image display of the whole board, 100% defect coverage.
