Product information
Equipment model equipment | LA320 | LA420 | LA500 | LA730 |
Packaging range | 5g-200g | 200g -lOOOg | 500g -2500g | lOOOg -5000g |
Packing speed | 40-7(W minutes 40-70bag/min | 35 - 60 bags/minute 35 - 60bag/min | 30 - 50 bags/minute 30-50bag/min | 20-4 5 bags/minute 20-45bag/min |
Packaging accuracy Packing accuracy | ±0.2%(Depending on material properties, particle size and other parameters) According to the material properties, particle size and other parameters | |||
Bag Form | Pillow-type bags (back sealing bags), hanging holes, punched bags, pin bags, box bags, four-sided sealing bags, envelope bags./ (Pillow type bag (back seal bag), punching hole bag, punching hole bag, pin type bag, box type bag, four side seal bag, envelope bag.) | |||
maximum film width Maximum membrane width | 320mm | 420mm | 500m m | 720mm |
Bag size Bag Size | L： 40〜190mm W:40 〜150mm | L： 80〜300mm W: 8。〜2 00mm | L： 100 〜350mm W:100 〜250mm | L： 100〜4 60 mm W:100 〜350mm |
Maximum outer diameter of packaging material Maximum packing diameter Compressed air | cp4 0 0 m m | q)4 0 0 m m | q)5 00mm | cp5 00mm |
Inner diameter of wrapping material paper core Wrapping paper core Inner diameter | cp3 0mm | cp75 m m | cp7 5 m m | cp7 5 m m |
compressed air | 6-8kgf/cm3, 0.30m3/min | 6-8kgf/cm3, 0.60m3/min | ||
power requirements Power requirements | AC380V±10%、 50-60HZ | AC380V±10%、 50-60HZ | ||
Overall power | 3.0KW | 4.5KW | 5.5KW | 6.5KW |
Machine weight | 500kg | 700kg | 800kg | 1000kg |
Overall size of the whole machine | L95XW65XH185cm | L115XW90XH360cm | L135XW120XH390cm | L175XW145XH420cm |
Brand Introduction
Hefei Xinyihua Intelligent Machinery Co., Ltd. was established in 2013. It is an advanced pan-semiconductor high-end equipment provider in China. It is mainly engaged in the research and development, production, sales and technical services of pan-semiconductor transfer equipment, process and testing equipment, industrial software and big data products. The company develops industries guided by the country's major strategic needs, solves technical problems for the industry and helps the development of the industry. Its business covers multiple first-level customers in the global industrial chain in pan-semiconductor fields such as display, semiconductors, LEDs, and photovoltaics. With advanced technology and continuous innovation capabilities, Hefei Xinyihua has become an important enabler of manufacturing in the pan-semiconductor field.
Hefei Xinyihua has built an 80,000-square-meter R & D and manufacturing base in Hefei New Station Area. Hosted and participated in a number of national key R & D plans and special projects for the revitalization and technological transformation of the national electronic information industry, led the preparation of relevant industry standards, and was invited to participate in the national "13th Five-Year Plan" scientific and technological innovation achievement exhibition.
As a national high-tech enterprise, Hefei Xinyihua has been recognized by innovation platforms such as Anhui Enterprise Technology Center, Anhui New Display Robot Engineering Research Center, Anhui Postdoctoral Scientific Research Station, etc., and has won the * first class * of innovation results of China's industry-university-research cooperation, Anhui Province Science and Technology * first class *, outstanding contribution to the development of China's new display industry chain *, special contribution to the development of China's new display industry chain *, innovative breakthrough in the development of China's new display industry chain *, First-class technological innovation achievements of employees in Anhui Province, quality of Anhui Province, famous brand products of Anhui Province, etc.
Brand Introduction
Hefei Sineva Intelligent Machine Co.,Ltd. was founded in July 2013, an advanced pan-semiconductor high-end equipment provider in China. We are mainly engaged in the R&D, production, sales and services of pan-semiconductor transfer equipment, process and inspection equipment，software and big data. Guided by the major strategic needs of industries, we are devoted to solving technical problems and promoting the development of industries. We have a number of Tier1 customers in the global industrial chain of pan-semiconductor fields. With the world's advanced technology and continuous innovation, we have become an important enabler in the pan-semiconductor manufacturing field.
Brand Development History
Brand Development History
Company Introduction
Hefei Xinyihua Intelligent Machinery Co., Ltd. was established in 2013. It is an advanced pan-semiconductor high-end equipment provider in China. It is mainly engaged in the research and development, production, sales and technical services of pan-semiconductor transfer equipment, process and testing equipment, industrial software and big data products. The company develops industries guided by the country's major strategic needs, solves technical problems for the industry and helps the development of the industry. Its business covers multiple first-level customers in the global industrial chain in pan-semiconductor fields such as display, semiconductors, LEDs, and photovoltaics. With advanced technology and continuous innovation capabilities, Hefei Xinyihua has become an important enabler of manufacturing in the pan-semiconductor field.
Hefei Xinyihua has built an 80,000-square-meter R & D and manufacturing base in Hefei New Station Area. Hosted and participated in a number of national key R & D plans and special projects for the revitalization and technological transformation of the national electronic information industry, led the preparation of relevant industry standards, and was invited to participate in the national "13th Five-Year Plan" scientific and technological innovation achievement exhibition.
As a national high-tech enterprise, Hefei Xinyihua has been recognized by innovation platforms such as Anhui Enterprise Technology Center, Anhui New Display Robot Engineering Research Center, Anhui Postdoctoral Scientific Research Station, etc., and has won the * first class * of innovation results of China's industry-university-research cooperation, Anhui Province Science and Technology * first class *, outstanding contribution to the development of China's new display industry chain *, special contribution to the development of China's new display industry chain *, innovative breakthrough in the development of China's new display industry chain *, First-class technological innovation achievements of employees in Anhui Province, quality of Anhui Province, and famous brand products of Anhui Province.
Pan semiconductor mobile equipment
Hefei Xinyi Hua started to lay out the R & D of clean handling robots since 2013. It is an enterprise that realizes the mass production application of display panel clean handling robots in China, and was invited to participate in the 2021 National "Thirteenth Five-Year Plan" Science and Technology Innovation Achievement Exhibition as the achievement of the national key R & D plan during the "Thirteenth Five-Year Plan" period.
Hefei Xinyi Hua is one of the leading suppliers of pan-semiconductor automation production equipment in China. The company can provide customers with overall solutions from automation production equipment, intelligent warehousing to factory information systems. At the same time, Hefei Xinyi Hua has become one of the few semiconductor AMHS overall solution suppliers in China that can provide complete software and hardware, customized products and localized supply chain. It has achieved full independent R & D breakthroughs in key technologies such as large-scale dynamic scheduling, high-speed operation and vibration control. It has multiple layout design capabilities of AMHS, and can flexibly arrange tracks and storage solutions according to customer needs to achieve optimal configuration and provide customers with all-round flexible customized solutions. The key parameters of semiconductor AMHS developed by Hefei Xinyi Hua, such as equipment running speed, vibration control, handling load and positioning accuracy, have reached the international advanced level, effectively assisting the advanced intelligent manufacturing of semiconductor industry.
Pan semiconductor process equipment
Hefei Xinyihua targets display, semiconductor, photovoltaic and other industries, focusing on developing pan-semiconductor core process equipment and solving core technical problems of advanced processes for customers. It has successively developed a huge amount of transfer equipment, evaporation equipment, key components, and laser equipment. Hefei Xinyihua is one of the few domestic equipment manufacturers that have completed the development and mass production of core process equipment such as OLED evaporation machines, perovskite evaporation machines and Mini/Micro LED mass transfer equipment, forming a new technical competitiveness and business growth point., and has won the trust of customers with excellent products and high-quality services, and its market share has expanded rapidly.
Pan-semiconductor testing equipment
Hefei Xinyihua can provide customers with optical and electrical testing equipment for LCD/OLED, Mini/Micro LED, and FPC production lines, including lighting AOI, appearance AOI, break/short circuit detection equipment, etc., to help customers break through technical problems and improve the whole process. Product testing system.
Industrial software and big data
Hefei Xinyihua integrates AI, big data, cloud computing, AIOT, industrial control and automation and other advanced analytical frameworks, technologies and tools to analyze and solve complex industrial, data science and business problems for corporate customers, such as digital transformation consulting, industrial software development, data collection and governance, intelligent detection and analysis, intelligent prediction, intelligent optimization and other services to help manufacturing companies reduce costs and increase efficiency, and achieve digital and intelligent transformation. At present, customers have covered display, photovoltaic, semiconductor, electronics and other industries.
core components
Hefei Xinyihua can provide customers with core components such as Mapping Sensors and vibration detection cameras.
Hefei Xinyihua will continue to focus on high-end manufacturing equipment with innovative technical capabilities and in-depth industry experience, improve the industrial layout, promote faster and better development of the industry, and contribute to China's high-level scientific and technological self-reliance.
Company Introduction
Hefei Xinyihua Intelligent Machine Co., Ltd. was founded in 2013, is China's advanced pan-semiconductor high-end equipment providers, mainly engaged in pan-semiconductor shift equipment, process and testing equipment, industrial software and big data and other products, research and development, production, sales and technical services. The company's major national strategic needs as the guide to do industry, for the industry to solve technical problems to help industry development, business covers the display, semiconductor, LED, photovoltaic and other pan-semiconductor field of the global industrial chain of a number of first-class customers. With advanced technology, and the ability of continuous innovation, Hefei Xinyihua has become an important enabler of manufacturing in the field of pan-semiconductor.
Hefei Xinyihua has built an 80,000 square metre R&D and manufacturing base in Hefei New Station District. Hefei Xinyihua has hosted and participated in a number of national key R&D programmes and special projects for the revitalisation and technological transformation of the national electronic information industry, led the compilation of relevant industry standards, and was invited to participate in the National 13th Five-Year Plan Exhibition of Scientific and Technological Innovation Achievements.
As a national high-tech enterprise, Hefei Xinyihua has won the recognition of Anhui Provincial Enterprise Technology Centre, Anhui Provincial Robotics Engineering Research Centre for New Display, Anhui Postdoctoral Research Station and other innovation platforms, and has won the first prize of the China Industry-University-Research Cooperation Innovation Achievement Award, the first prize of the Anhui Provincial Science and Technology Award, the Excellence Contribution Award for the Development of China's New Display Industry Chain, the Special Contribution Award for the Development of China's New Display Industry Chain
Pan-Semiconductor Shifting Equipment
Hefei Xinyihua began to layout the clean handling robot research and development in 2013, is the domestic display panel clean handling robot mass production application of enterprises, and as the "13th Five-Year Plan" during the national key R & D programme project results were invited to participate in the national "13th Five-Year Plan" in 2021. "Hefei Xinyihua is one of the most successful companies in China.
Hefei Xinyihua is one of the leading suppliers of automated production equipment for semiconductors in China. The company can provide customers with total solutions from automated production equipment, intelligent warehousing to factory information systems. At the same time, Hefei Xinyihua has become one of the few semiconductor AMHS solution providers in China that can provide complete sets of hardware and software, customised products, and localised supply chain, and has achieved breakthroughs in independent research and development in key technologies such as large-scale dynamic scheduling, high-speed operation, and vibration control, etc. It also possesses a variety of AMHS layout design capabilities, which allows it to flexibly lay out the track and storage solutions according to customer needs, and to realise the optimal configuration, providing customers with all-round flexible and flexible solutions. We are capable of designing various layouts of AMHS, and can flexibly arrange tracks and storage solutions according to customers' needs to achieve the optimal configuration, providing customers with a full range of flexible customised solutions. The key parameters of AMHS developed by Hefei Xinyihua have reached the international advanced level in terms of running speed, vibration control, load transfer, positioning accuracy, etc., which can effectively help the semiconductor industry's advanced intelligent manufacturing.
Pan-Semiconductor Process Equipment
Hefei Xinyihua, facing the display, semiconductor, photovoltaic and other industries, focuses on the development of pan-semiconductor core process equipment, to solve the core technical problems of the advanced process for customers, and has developed a huge amount of transfer equipment, vapour deposition equipment and key components, laser equipment. Hefei Xinyihua is one of the few domestic manufacturers who have completed the development and mass production application of core process equipment such as OLED evaporation machine, Calcite evaporation machine and Mini/Micro LED mass transfer equipment, forming a new technological competitiveness and business growth point, and winning the trust of customers with excellent products and high quality service, and rapidly expanding market share.
Pan-Semiconductor Testing Equipment
Hefei Xinyihua can provide customers with LCD/OLED, Mini/Micro LED, FPC production line optical and electrical inspection equipment, including light AOI, appearance AOI, break/short circuit inspection equipment, etc., to help customers break through technical problems and improve the whole process product inspection system.
Industrial Software and Big Data
Hefei Xinyihua integrates AI, big data, cloud computing, AIOT, industrial control and automation, and other advanced analytical frameworks, technologies and tools to analyse and solve complex industrial, data science and business problems for enterprise customers, such as digital transformation consulting, industrial software development, data collection and governance, intelligent detection and analysis, intelligent prediction, intelligent optimisation and other services, to assist manufacturing enterprises in reducing costs, increasing efficiency and achieve digital and intelligent transformation. Currently, our customers cover display, photovoltaic, semiconductor, electronics and other industries.
Core Components
Hefei Xinyihua can provide customers with core components such as Mapping Sensor and Vibration Detection Camera.
Hefei Xinyihua will continue to focus on high-end manufacturing equipment with innovative technology and deep industry experience, improve the industrial layout, promote faster and better development of the industry, and contribute to China's high level of scientific and technological self-improvement and self-reliance.
