Product information
Innovations
Self-developed cutter cooling system
Based on aerodynamics, making temperature during slitting effectively lower, which can improve slitting speed and yield.
Automatic Cutter Arrangement Design
6 sets of cutters can be adjusted automatically, and life management alarm equipped, which can improve the equipment availability and slitting accuracy.
Visual distance measurement and circular cutter stopping alarm function to enhance slitting accuracy and safety.
Self-developed CCD detection system
Various defects, such as pinholes, bumps, creases, indentations, etc., can be detected before and after slitting to ensure product quality.
Self-developed dust removal system
Based on aerodynamics, making the dust removal rate effectively improved and the quality of finished products greatly enhanced.
Innovative, efficient and safe design
Innovative roller quick-change structure solves the difficulties in the roller replacement and in unmaintainable bearings.
Infrared-assisted reference lines can make taping accurately, ensuring quality and consistency in winding.
Integrated hand pinching protection design and easy-to-reach emergency stop button can effectively prevent accidents and protect operators.
Sepecifications
| Parameter | Value | |
| Substrate | Thickness | 8-20 μm |
| Diameter | Max. .850 mm | |
| Weight | Max. .2000 KG | |
| Width | Max. .1650 mm | |
| Speed | Mechanical Speed | Max. .400 m/min |
| Production Speed | 30-350 m/min | |
| Slitting | Width | Min.200 mm |
| Width accuracy | ≤±0.5 mm | |
| Rewinding | Diameter | Max. .850 mm |
| Rewinding core | 3” & 6” optional | |
| Weight | 8200 KG | |
| Dimensions | L2800mm×W3600mm×H2700mm | |
| Power Capacity | 53 KW | |
