Collaborative Robot



Price:
price negotiable
Brand Name:
TurinRoboticsCountry Region:
ChinaModel No:
TR03-580C


TurinRobotics

Country: China
Main Products: Industrial robots, Software development
View more
Price:
price negotiable
Brand Name:
TurinRoboticsCountry Region:
ChinaModel No:
TR03-580C


TurinRobotics

China
Main Products:
Industrial robots, Software development

Product information
参数表
TR03-580C | |||
负载 | 3kg | ||
臂长 | 585mm | ||
轴数 | 6 | ||
供电电源 | 690~264VAC,47~63Hz/48VDC | ||
编程 | 拖动示教,图形化界面 | ||
安全 | 碰撞检测、虚拟墙、协作模式等 20 余项可调安全功能 | ||
认证 | EN ISO13849-1,Cat.3,EN ISO10218-1, 欧盟 CE 认证 | ||
重复定位精度 | ±0.03mm | ||
防护等级 | IP54IP67 | ||
最大速度 | J1 | 180°/s | |
J2 | 180°/s | ||
J3 | 180°/s | ||
J4 | 180°/s | ||
J5 | 180°/s | ||
J6 | 180°/s | ||
最大动作范围 | J1 | ±175° | |
J2 | ±175° | ||
J3 | -240°~60° | ||
J4 | ±175° | ||
J5 | ±175° | ||
J6 | ±360° | ||
噪音级 | Laeq≤85dB(A) | ||
额定功率 | 0.9kw | ||
适用环境 | 运行环境温度 | 0~45°C | |
环境湿度 | 20%~80%RH(无冷凝) | ||
本体重量 | 16kg | ||
适用控制柜 | TRC5-G06 | ||
安装方式 | 任意角度安装 |
参数图
