Name: ULTRA-WIDE-ANGLE LENS MTF TESTER (Tray mode)
Brand: AUTO-ALIGN
Price: price negotiable
Availability: InStock

1 / 4

ULTRA-WIDE-ANGLE LENS MTF TESTER (Tray mode)

Price：

price negotiable

Brand Name：

AUTO-ALIGN

Country Region：

China

Post Requirements

AUTO-ALIGN icon

Country： China

Main Products： 1. Research and development, manufacturing of lens MTF testing machines and accessories; 2. Research and development, manufacturing of lens AOI appearance inspection machines and accessories; 3. Research and development, manufacturing of AR/VR inspection machines; 4. Research and development, manufacturing of semiconductor wafer testing equipment.

Price：

price negotiable

Brand Name：

AUTO-ALIGN

Country Region：

China

Post Requirements

AUTO-ALIGN icon

China

Main Products：

1. Research and development, manufacturing of lens MTF testing machines and accessories; 2. Research and development, manufacturing of lens AOI appearance inspection machines and accessories; 3. Research and development, manufacturing of AR/VR inspection machines; 4. Research and development, manufacturing of semiconductor wafer testing equipment.

Product information

Explanation: It solves the problem of difficulty and potential interference with the telescopic objective when manually loading and unloading at ultra-large angles, and is particularly suitable for testing surround-view lenses in vehicles.

Key Parameter Item	Data
Measurement Mode	Infinite-conjugate
Supported Camera Quantity	Up to 25, typically configured as 9/13/17/21
Supported Test FOV (Field of View)	30° - 200°
Measurable Spatial Frequency	Up to 600lp/mm
Average MTF Measurement Time	1.3s per piece (TF process 21 steps)
On-axis Measurement Accuracy	1%
Off-axis Measurement Accuracy	2%
On-axis GR&R Extreme Difference	1%
Off-axis GR&R Extreme Difference	2%
Z-axis Position Accuracy	0.1um
Camera Position	1:1; 4:3
Testing Mode	Tray mode, tray is loaded externally, once loading is complete, the tray enters the test position for testing, and upon completion, the tray exits for unloading.

AUTO-ALIGN

China

Brand Introduction

Company Philosophy
Aolai Technology is committed to continuously developing innovative products and advancing technological progress. We are passionate about our endeavors. We focus on customer concerns and support their growth. We aspire to create value for our customers with advanced technology and top-notch service. We firmly believe that: Only by achieving our customers' success can we achieve our own.
Corporate Mission
To support high-precision detection in the micro and nano world.
Corporate Vision
Brilliant core light, sharing beauty together.
Values
Achieving customer success, taking responsibility, uniting in assistance, and growing together for mutual success.

Guangdong auto-align. Technology Co., Ltd

Company Introduction

Guangdong Aolai Technology Co., Ltd., established in 2019 and headquartered in Shenzhen,

is a national high-tech enterprise jointly founded by senior scientists and technologists from the fields of optics, semiconductors, machine vision, artificial intelligence,

and precision motion control, who have graduated from well-known domestic and international universities and have worked in top high-tech companies at home and abroad.

The company focuses on the field of high-end precision instruments and equipment in optical semiconductors,

researching leading technologies and algorithms in the areas of optical lens MTF testing, AR/VR optical testing, AOI appearance testing, and semiconductor wafer testing,

providing customers with efficient, leading precision testing instruments, high-end intelligent equipment, and production line automation solutions.

The company's industrial imaging quality MTF measuring instrument has successfully achieved domestic substitution and has the world's fastest testing efficiency!

It has won the third prize in the finals of the 13th China Shenzhen Innovation and Entrepreneurship Competition and the Excellent Enterprise Award in the 10th China Innovation and Entrepreneurship Competition.
