Product information
Introduction of rotating platform fiber laser cutting machine
Laser cutting automatic rotating machine: including coil material rack, leveling device, laser machine bed, material receiving platform, automatic blade rotating assembly;
Working principle: the first feeding coil material is leveled by the leveling machine and then enters the laser cutting platform for cutting. After the cutting is completed, the leveling machine automatically feeds the material, and the rotating platform automatically transports the cut parts to the receiving platform. After the leveling machine feeds the material, the system runs to cut the second layout drawing material, and at the same time, the numbering and collection of the first material can be carried out. This reciprocating work greatly improves the overall processing speed and efficiency.
Comparison between rotary platform laser cutting machine and ordinary laser cutting machine
(1) Cutting efficiency is higher, reducing the time of loading the plate, and only needing to pick up the waste material, the efficiency is increased by 50%.
(2) Improve the efficiency of plate use, realize the cutting of the amount of plate used, and avoid the disadvantage of each plate needing to be sized and compensated.
(3) Reduce the intensity of manual labor. No need to cut the material in advance, no need to lift the plate manually. Greatly improve work efficiency.
(4) It can realize one system control, automatic sorting and processing, manual and automatic integration. The operation is simple and easy to use, which is more user-friendly than ordinary machines that need to import graphics every time.
(5) The laser head and laser are perfectly matched to achieve the improvement of the machine's thin plate speed.
Equipment parameters
Raw materials | Cold rolled sheet, galvanized sheet, stainless steel | |
2 | Plate thickness | 0.5mm ～ 2.0mm |
3 | Plate width | 1000mm～1500mm |
4 | Weight per roll | ≤10T |
5 | Inside diameter of roll | Ø508mm-Ø630mm |
6 | Outer diameter of roll | Ø1000 ~ Ø1600mm |
Finished product parameters
1 | Surface quality | The surface of the strip is flat and does not add any processing defects; |
2 | Leveling accuracy | ±1mm / m2 |
3 | Diagonal accuracy | ≤1mm/2000mm |
Unit Parameters
1 | Belt speed | 5m/min |
2 | Line speed of the unit | Straightening machine line speed 0～12m/min （adjustable） |
3 | Running Elevation | +800mm |
6 | Running direction | （Subject to final plant process layout） |
Working conditions for equipment use
1 | Power conditions | 3φ alternating current, 400V±5%，50Hz±2% |
2 | Air source （compressed air） | Pressure: 0.5～0.6MPa Displacement: 0.6m3/min |
3 | water source | No special requirements |
Machine tool workbench
The frame structure is welded with high-quality steel plates and pipes, and the secondary aging treatment and large gantry milling machine are used for precision processing. These design and processing methods ensure that the machine tool has excellent seismic resistance, high rigidity and stability. The workbench adopts a top-type dense workbench and a rotating platform design, which can prepare for the next loading while processing, greatly improving work efficiency.
Dust removal system
The workbench adopts a centralized dust collection design and is equipped with a dust collection pipeline to remove dust, exhaust gas and other substances during the production process.
Transmission system: It adopts high-precision grinding rack precise transmission and servo control system to ensure the stability and accuracy of the machine tool under high-speed motion.
CNC control system: The CNC cutting control program is developed based on the windows system and can be fully connected with the CNC control system. It is a professional CNC software for laser cutting. It uses professional PC industrial control computer operation and a graphical interface for easy operation. The interface is friendly, easy to learn, and easy to operate. The CNC CNC program is easy to edit and has strong readability. , AutoCAD, CorelDraw and other professional drawing software, equipped with a cutting process parameter database, the cutting parameters can be adjusted in real time during the cutting process to achieve the best cutting quality.
Nesting software
(1) Drawing and programming nesting software specially developed for CNC cutting machines and used on computers. The main functions include CAD drawing, the new version of CAM-DUCT duct decomposition software, DXF/DWG optimization processing, interactive nesting, automatic programming, as well as cutting simulation verification and cost calculation.
(2) CAM-Duct duct software The software comes with 300+ duct graphics The software can layout multiple graphics at a time Oversized plate graphics can be automatically split and spliced Automatically reserve the splicing interface size.
(3) Nesting software is the core technology for CNC cutting machines to achieve "full-time cutting, high-efficiency cutting and high nesting rate cutting", and is the fundamental guarantee for effectively saving steel and improving cutting efficiency.
Cooling method
Professional-grade water cooling system can achieve dual temperature and dual control. Two water circuits cool two core positions respectively. The temperature of the refrigeration unit is displayed in a digital meter. When the water temperature exceeds the specified temperature, the refrigeration unit will automatically cool. When the water temperature is lower than the specified temperature, the refrigeration unit will automatically stop cooling.
Service Commitment
Pre-sale service:
According to the development needs of customers, from the point of view of the actual use of customers, to provide appropriate technical guidance and a full set of equipment information;
Solve the various problems raised by customers, from the technical feasibility considerations, for customers or to assist customers in the design and development of laser processing program;
Provide equipment display so that customers can visit the inspection, sampling, test machine and so on.
In-sale service:
The actual use of the customer's machine site inspection and analysis, according to the customer's site to assist users in planning and design of the site as well as water, electricity, gas arrangements for the equipment and so on;
Provide customers with a full set of equipment operation manuals, equipment operators to provide training to customers;
After-sales service:
In the user's use of the site, the customer's equipment operators for the actual operation of the processing, daily maintenance of equipment and safe use of the protection of the training to ensure that the user can master the equipment operating procedures and methods as soon as possible, and can independently use the equipment for production and processing;
The whole set of equipment in the user after installation and commissioning, since the date of training into the machine one year warranty period, the laser two years warranty period;
In the warranty period, the company will also assign customer service specialists to the user's equipment from time to time to carry out technical patrols on the work site, the equipment to do from time to time routine maintenance and inspection, to answer questions raised by the user.
Other matters
1、Project progress
Cycle time of about 45-60 working days, according to the contract cycle time to complete the design, manufacturing and acceptance of work and sent to the demand side.
2、Installation and commissioning
Equipment shipped to the demand side, 7-10 days of installation and commissioning cycle.
