Three Linear guide way vertical machining center
iconicon
Post RequirementsPost Requirements
BOHO MACHIENRY
BOHO MACHIENRY icon
View more
Post RequirementsPost Requirements
BOHO MACHIENRY
BOHO MACHIENRY icon
China
Main Products:
CNC machine
icon

Product information

ItemMV-865Unit
Work tableWork table size1000*500mm
MAX. Load capacity550kg
T slot(number of slot-size* distance)5-18*100mm
Work
capacity
Travel of X/Y/Z axis800/550/580mm
Distance from spindle centerline to column guide surface570mm
Distance from spindle nose to work table surface100-700mm
SpindleSpindle taper specificationsBT40-150
Spindle speed12000r/min
Spindle motor power7.5/11kW
Spindle drive typeDirect-connected spindle

ToolTaperBT40
Pull studs specificationsBT40-I
Feed
X/Y/Z axis serve motor power13/13/22Nm
X/Y/Z axis serve motor speed3000/3000/3000rpm
X/Y/Z axis guide wayXYZ:45/45/45Linear rollermm
feed1-10000mm/min
Min. feed0.001mm
CNC controller systemHNC/MITSUBISHI/FANUC/
Others
