1.The VMB04 series pumps are horizontal, single-casing, top suction and discharge, centerline-supported, radially split, ring-section multistage high-pressure boiler feedwater pumps, classified as API 610 BB4 type.

2. Product Features

Customized for power plant boiler feedwater, industrial high-pressure water supply, and oilfield water injection.

Independent R&D building upon international design concepts and manufacturing experience.

Excellent hydraulics utilizing CFD and ANSYS software.

Internationally advanced, representing a new generation of high-efficiency and energy-saving product.

Specifically designed for extreme conditions such as high temperature and pressure.

Equipped with high-temperature limiting devices to effectively address vibration caused by thermal expansion.

Pressure-bearing middle and discharge sections are forged, ensuring safety and reliability through advanced processes.

Shrink fitting between impellers and shaft enhances rotor rigidity and reduces vibration.

Stage-by-stage impeller positioning avoids cumulative errors and thermal deformation effects.

Staggered keyways for uniform torque transmission; staggered vanes for reduced resonance.

Axial forces efficiently balanced via a combined balancing drum and balancing disc structure.

Overall design balances high efficiency with adaptability to harsh conditions, ensuring long-term stable operation through precision manufacturing and structural optimization.

3. Performance Range

Flow Rate (Q): 25~900 m³/h

Head (H): ~2400 m

Rotational Speed (n): 1480, 2980 rpm

Design Pressure (P): 15.0, 26.0 MPa

Operating Temperature (T): -80℃ to +210℃

4. Applications

Petroleum Processing, Production, and Transportation,Coal Chemical Processes,Petrochemical and Chemical Processes,Metallurgy,Oilfield Water Injection,Boiler Feedwater,Water Supply and Treatment,General Industry.
