Gantry five-axis five-linkage machining center DPC-U 500H
iconiconicon
Post RequirementsPost Requirements
DAPAN PRECISION  MACHINERY
DAPAN PRECISION MACHINERY icon
View more
Post RequirementsPost Requirements
DAPAN PRECISION  MACHINERY
DAPAN PRECISION MACHINERY icon
China
Main Products:
Gantry five-axis five-linkage machining center, crown crane five-axis linkage machining center, engraving and milling machine, vertical machining center, gantry medium and high-speed machine, gantry roughing machine, gantry graphite machine
icon

Product information

serial number project                      DPC-U500H

1

stroke

x-axis travel

630MM

2

y-axis travel

800MM

3

Z-axis stroke

450MM

4

Distance from table top to spindle nose

150-600MM

5

turntable

model

DD Turntable

6

A-axis rotation angle and rated speed

+30º-120º- 100RPM

7

C-axis rotation angle and rated speed

360º- 100RPM

8

workbench

workpiece range

¢630MM

9

loading

Horizontal placement 400KG, 0-90º tilt load 250KG

10

the clamping face of the

¢500MM

11

Countertop shape

circular

12

spindle

model

BT40/HSKA63

13

spindle speed

15000RPM

14

transmission mode

direct connection type

15

spindle motor

10.6kW

16

Spindle taper hole diameter

Ф150

17

spindle torque

                     45-103.3Nm

18

feed

Three-axis moving speed

30m/min

19

workpiece cutting speed

0-10m/min

20

Three-axis linear guide rail configuration rail width

X axis: RG35

Y axis: RG35

Z axis: RG35

21

Three-axis ball screw diameter

X axis: Φ36MM

Y axis: Φ36MM

Z axis: Φ36MM

22

tool changing system

Tool magazine method

Disc type tool magazine

23

tool changer capacity

24

24

Knife magazine * large length

250MM

25

Knife magazine * large weight

8kg

26

tool magazine motor

60W

27

accuracy

Three-axis positioning accuracy/AC axis

0.008mm/±5"

28

Three-axis repetitive positioning accuracy/AC axis

0.005mm/±5"

29

other

Air source demand

5~7kg

30

air-conditioners

4A

28

Power demand specifications

50KVA

29

Machine tool external size (length * width * height)

2930*2550*2850mm

30

W/G. W

9000/9500kg

 Note: Due to the continuous research and development of our company's technology, if there are changes to the model parameters and technical specifications, the specific specifications will be subject to the time of business negotiation, and the technical parameters are for reference only.
