1. System overview

This series of products is aimed at various label printing industries and narrow width printing industries. It can static the image quality of high-speed printing online on the display screen, so as to adjust the printing process and parameters and monitor the printing quality by operators. This system is usually used to monitor printing overprint cross marks or zoom in on important identification areas.

2. System characteristics

1. It adopts a high-speed area-array CMOS chip and a professional electric lens, with 10x optical zoom, large aperture, high image resolution, clear shooting pictures, and excellent restoration.

2. Equipped with a large-screen high-definition LCD display for higher image clarity.

3. Select high-performance hardware and unique image digitization technology to provide the following

Features:

① Capture the screen freezing function, making it easier to analyze printing quality at any time;

② Capture screen adjustment function, which can adjust the position that needs real-time monitoring;

③ Automatic detection, automatically capturing the printed surface in different ways according to needs;

④ The autofocus function makes it easier to zoom in and out images.

4. The system control line uses professional cables and high-quality drag chains, which are resistant to bending and have a long life.

5. It can support external synchronous triggering such as encoder, proximity switch and gear sensor, making it easy to install.

6. The optical reflector is optimized and the diffuser plate made of high-end materials makes the exposure even and soft and has high brightness.

3. Performance indicators

1. Adapt power supply: 220V±10%, 50Hz;

2. Adapt to ambient temperature: 0-40℃;

3. Applicable monitoring speed: up to 1200 m/min;

4. Camera: CMOS chip digital camera, 2 megapixels;

5. Lens: 10x optical zoom technology, segmented focus, with good self-learning ability;

6. Image magnification: about 25 times;

7. Monitoring range: minimum 17×13mm, maximum 113×94mm;

8. Image capture methods: automatic and manual capture methods;

9. Working mode: stop, manual, horizontal inspection, horizontal equidistant, vertical equidistant, line-by-line inspection, column-by-column inspection;

10. Lateral moving speed: less than 6 meters/minute;

11. Picture synchronization method: gear sensor, proximity switch, encoder, etc. Gear number setting range: 1-9999;

12. Frequency range of synchronous signal: pulse signals up to 30kHz can be detected;

13. Display: 21.5-inch VA display, wide viewing angle, optional telescopic bracket;

14. Overall size of the camera unit (length, width and height): 140mm × 100mm × 280mm.
