Product information
1. There are a complete range of products, divided into three categories: ceiling type, vertical type and horizontal type. There are two types of ceiling-mounted units: ordinary and long-distance jet. The general category can be installed with 2, 4, 6, and 8 rows of pipes, with the air volume ranging from 1000m2/h to 15000m2/h, and the cooling capacity ranging from 3.2W to 135.5W (with return air), and 7.6KW to 260KW (new air); The remote jet category can be installed with 4 and 6 rows of pipes, with the air volume ranging from 3000m2/h to 30000m2/h, and the cooling capacity ranging from 6.6KW to 94.4KW (with return air), and 12.9KW to 191.2KW (new air). Horizontal units can be equipped with 2, 4, 6, and 8 rows of pipes. The air volume ranges from 1000m2/h to 30000m2/h, and the cooling capacity ranges from 9.6W to 270.9KW (with return air), and from 22.9KW to 530KW (new air). Vertical units are divided into two series: CVA and CV-LM. The CVA series can be installed in 2, 4, 6, and 8 rows of pipes, with the air volume ranging from 1000m2/h to 8000m2/h, and the cooling capacity ranging from 7.6W to 72W (with return air), and 22.9KW to 158.4KW (new air); The CV-LM series can be installed in 4 and 6 rows of pipes, with the air volume ranging from 3000m2/h to 12000m2/h, and the cooling capacity ranging from 16.3KW to 94.1KW (with return air), and 38.7KW to 192.7KW (new air). Various models have standard specifications and can be flexibly selected according to needs. 2. The fan adopts metal impeller. After dynamic and static balance testing, it runs smoothly, has low noise and high efficiency. The motor adopts a three-phase asynchronous high-efficiency motor, and can be equipped with a variable air volume speed regulating device to adjust the speed to adapt to multiple load changes. The steel plate is made of zinc aluminum plate with high corrosion resistance and is matched with perfect rice and gold technology. The surface is beautiful and durable. The heat exchanger adopts today's * advanced LF corrugated bridge-slit hydrophilic film aluminum fins. Through unique tube expansion technology, it is closely integrated with copper tubes, which has the advantages of high efficiency, energy conservation and environmental protection. The filter adopts a long-life antibacterial and mildewproof filter, which is easy to install, can be cleaned repeatedly, and saves user investment. 3. The unit has the characteristics of low air leakage rate and high thermal insulation. The domestic unique design, the joint of the box body adopts concealed thermal insulation and sealing treatment, and is combined with vortex type sunk nail connection, so that the air leakage rate is extremely low. The unit panels are made of foam insulation with high density and low thermal conductivity to increase the strength and insulation performance of the box. At the same time, thermal insulation connections and sealing parts are used to avoid direct contact between heat conduction parts, completely eliminate cold bridges, and eliminate cold loss. Through unique tube expansion technology, it is closely integrated with copper tube, which has the advantages of high efficiency, energy saving and environmental protection. Filter: Long-life antibacterial and mildewproof filter, easy to install, can be cleaned repeatedly, saving user investment. 4. In terms of supply, new shaped steel components are used, which can not only be transported and moved in as a whole, but also independently transported to the site for assembly as needed. Suitable for the size requirements of any handling channel and machine room. In terms of maintenance, an all-steel insulation airtight door is used for flexible opening. Reserve space inside the equipment for convenient maintenance.
